TECHNICAL SPECIFICATIONS:

Drilling capacity: 45 mm

Spindle stroke: 140 mm

Morse taper: No . 4

Automatic feed per spindle revolution: 0.06, 0.12, 0.25 mm

Useful table dimensions: 270 x 800 mm

Longitudinal travel of the table: 540 mm

Cross travel of the table: 265 mm

Distance between the column and the center of the spindle: 300 mm

Maximum distance between the cone and the table: 680 mm

Automatic vertical table travel: 570 mm

Max spindle speed: 1,650 rpm

Engine: 3 kW / 4 Hp

Approximate net weight: 800 kg

Overall dimensions: 1,365 x 1,930 x 2,060 mm

The images and technical specifications are provided for illustrative purposes only and do not constitute a contractual element.
