Technical Specifications
Height of the tips on the bench: 360 mm
Bench width: 450 mm
Width of the recess: 450 mm
Maximum turning diameter on the lathe: 750 mm
Maximum turning diameter on the grooved surface: 910 mm
Maximum turning diameter on the slide: 470 mm
Spindle bore diameter: 150 mm
Year built: 2011
Machine comes complete with:
-Pinto self-centering double guide, 450 mm diameter, 3+3 jaws
-Closed steady rest
-Open steady rest
-Heidenhain 2-axis position indicator
-Instruction manuals
-Type D tool turret
