Technical Specifications
TECHNICAL SPECIFICATIONS:
- CNC: GE-FANUC 21i
- Max. diameter of workpiece on the bench: 720 mm
- Maximum turnable diameter: 590 mm
- Maximum turnable length: 2,000 mm
- Spindle mount: DIN 55026 A2-11”
- Front bearing diameter: 180 mm
- Continuous spindle motor power (100% duty cycle): 25 kW
- Maximum torque at 165 rpm: 2,300 NM
- Spindle speed: rpm 20–2,000
- Self-centering diameter: 400 mm
- Bar clearance: 124 mm
- Rapid feed rate in the X-Z axis: M/1’ 20
- VDI tool holder: 50 mm
- Fixed tool stations: 12
- Rotary tool stations: 6
- Rotating tool power: 7.5 kW
- Rotating tool speed: 2,500 G/1’
- Tailstock quill diameter/stroke: 120/150 mm
- Jig head thrust: 16,000 N
ACCESSORIES
- Oil Separator for Chip Conveyor
- Fume extractor without a catalytic converter
- Set of 12 tool holders
- AUTOBLOCK 400 GHD ASA 11” Self-Centering Chuck, 3+3 Jaws
- No. 02 axial modules
- No. 02 radial modules
