Technical Specifications
TECHNICAL SPECIFICATIONS:
Maximum diameter at centers: 200 mm
Maximum allowable distance between centers: 550 mm
Maximum allowable distance between workpiece holder and tailstock: 425 mm
Table dimensions: 800 x 112 mm
Table orientation: 360°
Longitudinal table travel: 400 mm
Vertical travel of the grinding head: 250 mm
Transverse travel of the grinding head: 300 mm
Grinding head orientation: 360°
Horizontal oscillation of the grinding head: +/- 30°
Max. cylindrical grinding length: 400 mm
Max. mounted grinding wheel diameter: 150 mm
Grinding wheel spindle speed: 3000/6000
Machine weight without accessories: 700 kg
