Technical Specifications
TECHNICAL DATA:
Heidenhain iTNC 530 HSCI CNC
TRAVELS:
X-axis travel: 800 mm
Y-axis travel: 1,050 mm
Z-axis travel: 800 mm
B-axis travel: 180°
C-axis travel: 360°
SPECIFICATIONS:
Rapid feed speed in the X, Y, and Z axes: 40,000 mm/min
Acceleration in the X, Y, and Z axes: 7 / 6.5 / 6.5 m/s²
ELECTRO SPINDLE:
Electrospindle rotation speed: 18,000 rpm
Tool attachment cone: ISO 40
Electrospindle power: 35 kW
Torque: 130 Nm
TABLE:
Mounting surface: 800 x 630 mm
Maximum capacity: 1,000 kg
Machine equipped with:
• 240-position tool changer
• Heidenhain TS640 workpiece probe
• Tool breakage detection in the tool magazine
• QuickSET 3D compatibility
• High-pressure spindle (40 bar)
• Tank with paper filter
• Integrated fume extractor
• Side control panel for tool loading/unloading
• Power failure protection package
• FASTEMS automation preparation
• Instruction manuals and CE declaration
Year of construction: 2011
