TECHNICAL DATA:

Heidenhain iTNC 530 CNC

WORK AREA:

Longitudinal X: 500 mm

Transverse Y: 450 mm

Vertical Z: 400 mm

B axis: -5°/+110°

C-axis: 360°

SPINDLE:

Spindle connection cone: BT 40

Rotation speed: 20–8,000 rpm

Maximum drive power (25% duty cycle / nominal 100%): 13/9 kW

ADVANCEMENTS:

X, Y, Z-axis feed: 24,000 mm/min

Rapid X, Y, Z: 24,000 mm/min

TOOL WAREHOUSE:

Warehouse spaces: 30

Max. tool diameter with adjacent spaces available: 80 / 130 mm

Max. tool length: 300 mm

Max. tool weight: 6 kg

Machine weight: 4 ,000 kg

Year of construction: 2012

The images and technical specifications are provided for illustrative purposes only and do not constitute a contractual element.
