TECHNICAL SPECIFICATIONS:

Selca 4045 CNC

WORK AREA:

Longitudinal stroke X: 850 mm

Y-axis travel: 600 mm

Z-axis vertical travel: 600 mm

CHUCK:

Tool holder taper: ISO 40

Rotational speed: 8,000 rpm

AC Motor Power – kW/30 min: 11 kW

TABLE:

Dimensions: 1,050 x 600 mm

Maximum weight allowed on the board: 600 kg

TOOL CHANGE:

Number of tools: 24

Tool dimensions, Ø x L: 90 x 250 mm

Tool weight: 8 kg

Machine weight: 6,500 kg

Year built: 2006

The images and technical specifications are provided for illustrative purposes only and do not constitute a contractual element.
