Technical Specifications
TECHNICAL SPECIFICATIONS:
Tip height: 250 mm
Nominal distance between centers: 1500 mm
Spindle bore: 105 mm
Spindle reduction sleeve: CM 5
Front bearing diameter: 140 mm
Rear bearing diameter: 130 mm
Overhang above the bench: 505 mm
Max. diameter that can be turned on the slide: 285 mm
Max. diameter that can be machined with the CMT cutting tool: 445 mm
Transverse slide travel: 270 mm
Tool carriage travel: 170 mm
Counter width: 330 mm
Distance from the end of the nose to the spindle: 270 mm
Fixed bezel working range: 10 to 185 mm
Working range of the movable caliper: 16 to 105 mm
Diameter of the counterflange: 68 mm
Dashboard travel: 200 mm
Tailstock taper: CM 5
Standard engine power: 7.5 kW
Spindle speed: n. 16
Rotation speed range: 23–1000 g/min
Work Progress: No . 28
Longitudinal advances: From 0.06 to 0.84
Cross-feed: From 0.03 to 0.042
