TECHNICAL SPECIFICATIONS:

• CAPACITY:Center height on the bench: 200 mmDistance between centers: 1 ,000 mmMaximum diameter on the bench: 400mm

  Maximum diameter on the slide: 230 mm

  BANK:

  Bench width: 260 mm

  HEAD:

  Spindle bore: 52 mm

  Spindle nose: CAMLOCK 6’’

  SPEED:

  Spindle speed: n . 16

  Spindle speed: rpm 36/1,600

  FEED RATES AND THREADS:

  72 longitudinal feeds: 0.050 – 4.45 mm/rev

  72 cross-feed rates: 0.025–2.25 mm/rev

  54 Whitworth threads: TPI 1–56

  54 metric pitches: 0.5–28 mm

  54 steps (English): 1/32 inch – 1 inch

  54 modular pitches: 0.25–14 mm

  54 pitches: D .P. 2–112

  CROSS SLIDE:

  Length: 470 mm

  Width: 180 mm

  Maximum stroke: 190 mm

  TOOL TRAY:

  Length: 260 mm

  Width: 120 mm

  Maximum stroke: 145 mm

  Rotation angle: 360°

  COUNTER-PROTEST:

  Hub diameter: 58 mm

  Steerer tube length: 265 mm

  Maximum hub travel: 120 mm

  Counter-rotating Morse taper: No. 4 taper

  ENGINE:

  Power: 4 kW

The images and technical specifications are provided for illustrative purposes only and do not constitute a contractual element.
