Technical Specifications
TECHNICAL SPECIFICATIONS:
Fanuc 21i-T CNC
WORK CAPACITY:
Maximum diameter that can be turned on the lathe: 550 mm
Rotating diameter on the cross slide: 340 mm
Maximum diameter that can be turned with external tools: 450 mm
Distance between the spindle nose and the swivel tailstock: 1.275 mm
Maximum turnable length: 1,100 mm
HEAD AND SPINDLE:
DIN 55026 Spindle Mount: A2-8’’
Inner diameter of front bearing: 130 mm
Self-centering diameter: 315 mm
Useful bar clearance: 84 mm
Continuous/intermittent spindle power: 34/45 kW
Max torque at 650 rpm: 480 Nm
Electrospindle speed: 20–3,500 rpm
COUNTERPOINT:
Hub diameter: 95 mm
Steerer tube travel: 135 mm
Max continuous thrust: 11,300 N
Tip: MK 5
X- and Z-AXIS SLIDES:
X-Z-axis travel: 300–1,160 mm
Motorized tool stations: 12
INSTALLATION INFORMATION:
Total installed power: 37 kVA
Machine weight: 7,500 kg
Overall dimensions: 4,760 x 1,960 x 2,100h mm
Machine comes complete with:
- Axis C
- Bezel
- Tailstock
- Instruction Manuals and EC Declaration
