Technical Specifications
TECHNICAL SPECIFICATIONS:
Maximum diameter that can be turned on the lathe: 640 mm
Rotating diameter at the natural recess: 840 mm
Turning diameter on the cross slide: 460 mm
Counter width: 420 mm
Effective length of the natural groove: 518 mm
Min. and max. speed No. 24: 28–1,600 rpm
Spindle nose type: D1 8’’
Spindle bore diameter: 102 mm
Throat depth: 240 mm
Tailstock spindle diameter: 100 mm
Length of tailstock spindle: 390 mm
Tailstock MORSE taper: No . 5
Transverse carriage travel: 410 mm
Tool carriage travel: 200 mm
Distance between the tips: 2,000 mm
Net weight: 3,800 kg
Machine comes complete with:
- Heidenhain Coordinate Display
- 2 Lunettes
- Instruction Manuals
