Technical Specifications
A machine with high structural rigidity, high material removal capacity, precision, and maneuverability, allowing the operator to always work under the best conditions.
SELCA 4045 NUMERICAL CONTROL SYSTEM
TABLE: Dimensions: 2750 x 815 mm
STROKE:
Longitudinal: 1800 mm
Transverse: 620 mm
Vertical: 550 mm
VERTICAL HEAD: Model TSVE
SPINDLE:
ISO/HSK 63 mounting cone
RPM 16,000
Head rotation 340°
FEED RATES:
Variable mm/1’ 0 – 12000
Rapid mm/1’ 0 – 12000
REFRIGERANT PUMP:
Pressure (bar) 4/14
Flow rate (L/min) 20
WEIGHT: 11,300 kg
The images and technical specifications are provided for illustrative purposes only and do not constitute a contractual element.
Machine comes complete with:
ACCESSORI IN DOTAZIONE:
•TAVOLA GIREVOLE IN CONTINUA INCASSATA
•MAGAZZINO CAMBIO UTENSILI LATERALE A RUOTA
•EVACUATORE TRUCIOLI
•Manuali d’istruzione e dichiarazione CE
