TECHNICAL DATA:

Fanuc 18-iMB CNC

WORK AREA:

Table dimensions: 1,200 x 500 mm

Longitudinal X: 1,020 mm

Y-axis: 500 mm

Vertical Z: 500 mm

Table load capacity: 500 kg

FEEDS:

Rapids X / Y / Z axes: 40,000 mm/min

SPINDLE:

Spindle taper: ISO 40

Max spindle speed: 12,000 rpm

Spindle power: 18.5 kW

TOOL CHANGER:

Tool selection: Random

Number of tools in stock: 30

Chip-to-chip tool change time: 4 sec

DIMENSIONS:

Machine dimensions: 2,535 x 2,465 x 2,750 mm (h)

Weight: 6.850 kg

Machine comes complete with:

• High pressure through the spindle
• Instruction manuals and CE declaration

Year of construction: 2007

The images and technical specifications are provided for illustrative purposes only and do not constitute a contractual element.
