Specifiche tecniche
SPECIFICHE TECNICHE:
CNC Heidenhain TNC 430
WORKING AREA:
Longitudinal travel X axis: 1.800 mm
Y axis cross travel: 1.250 mm
Vertical travel Z axis: 1.250 mm
B axis rotary table: 0 – 360 °
SPINDLE:
Spindle taper: ISO 50
DIN 2080 cone: VDI 2814
Front bearing diameter: 105 mm
Spindle power: kW 28
Maximum torque: 924 Nm
Speed range: 10 – 3.300 rpm
TABLE:
Table dimensions: mm 1.400 x 1.400
Max loading weight: kg 5.000
FEEDS:
X Y Z axis feeds: 2 – 5.000 mm/min
Fast X Y Z axes: 10.000 mm/min
Rapid axis B: 2 rpm
Rapid W axis: 8.000 mm/min
TOOLS CHANGER:
Tool stations: Nr. 60
Max tool length: 500 mm
Max tool weight: 25 kg
Very well equipped machine (numerous tools)
Year of construction: 2002
