TECHNICAL SPECIFICATIONS:

Automatic dual-rotating head with 2.5° indexing

Heidenhain TNC 426 CB CNC

Sidepalsa 40-position tool changer

Spindle Cooling

Blum Electronic Prober

RACES

X-axis longitudinal travel: 4,000 mm

Vertical travel along the Z-axis: 2,000 mm

Y-axis traverse: 1,200 mm

PROGRESS

Feed rates: 0–8,000 mm/min

Rapid feed rates: 15,000 mm/min

Axial thrust: 2,000 DaN

CHUCK

AC motor power: 36 kW

Spindle taper: ISO 50

Spindle speed at constant torque: 0–190 rpm

Spindle speed at constant power: 190–3,000 rpm

Max. spindletorque: 1,400 Nm

GENERAL INFORMATION

Total installed capacity: 51.5 kW

Net weight: 25,500 kg

Year built: 1999

The images and technical specifications are provided for illustrative purposes only and do not constitute a contractual element.
