Technical Specifications
TECHNICAL SPECIFICATIONS
HEAD
Spindle sleeve outer diameter: 95 mm
Spindle cone: ISO 40
Spindle sleeve stroke: 130 mm
Spindle speed: 70 to 4000 rpm
Automatic feed rates per revolution: 0.05 – 0.10 – 0.15
TABLE Work surface: 280×1100 mm
Number of T-slots: 4 x 16
Bidirectional orientation: 45°
Longitudinal stroke: 800 mm
Transverse stroke: 250 mm
Vertical stroke: 400 mm
FEED RATES
Longitudinal: mm/min 15 ÷ 1160
Transverse: mm/min 15 ÷ 1160
Vertical: 7–585 mm/min
Longitudinal rapid feed: 2000 mm/min
Transverse rapid feed: 2000 mm/min
Vertical rapid feed: 1000 mm/min
Maximum distance between the rapid-feed spindle head and the table surface: 530 mm
POWER
Main motor: 4 HP
TV4 head motor: 3 / 2.5 HP
Feed motor: 1 HP
Electric pump motor: 0.20 HP
WEIGHT: 2000 kg
OVERALL DIMENSIONS
: Width x Length x Height: 1200 x 1200 x 2300 mm
Year: 1997
The images and technical specifications are provided for illustrative purposes only and do not constitute a contractual element.
Machine comes complete with:
Macchina completa di:
• Visualizzatore di quote 4 assi
• Manuali d’istruzione e Dichiarazione CE
