TECHNICAL SPECIFICATIONS:

Table dimensions: 1,600 x 560 mm

Cross travel of the table: 560 mm

Longitudinal travel of the table: 1,200 mm

Vertical head travel: 725 mm

Vertical spindle travel: 160 mm

Table cross-feed and longitudinal feed rates: 2,000 mm/min

Vertical rapid traverse of the head: 400 mm/min

Spindle taper: ISO 40

Spindle bore diameter: 140 mm

Spindle speed: 40–2,000 rpm

Distance between the spindle nose and the table surface: 0–725 mm

Head rotation in the vertical plane: ± 45°

Dimensions: 2,370 x 2,300 x 2,540h mm

Weight: 5,200 kg

The images and technical specifications are provided for illustrative purposes only and do not constitute a contractual element.
